JLG 2630ES

Key Specs
  • Platform Height : 25 ft 6 in. / 7.77 m
  • Platform Capacity : 507 lb / 229.97 kg
  • Machine Width : 5 2 ft 8 in. / 0.81 m
  • Drive Speed – Platform Lowered : 3 mph / 4.83 km/h
Key Features
  • Run Longer on a Single Charge: Delivers double the battery life*
  • Work in Sensitive Areas: Available CleanGuard leak containment system allows for work on sensitive flooring
  • Reduce Operating Costs: Electric drive and integrated components with reduced hydraulic components on the entire machine lower the chances for leaks and service calls to keep you on the job longer
  • Increase Your Maneuverability: Narrow width fits through most standard doorways and tight aisles
  • Standard LED Motion/Amber Beacon with ClearSky Smart Fleet™ Connectivity Hardware
Power Source
Batteries 4 x 6V 220 A-h
Charger 27 amp High Frequency Charger
General Specifications
Brakes Multi-disc Friction
Capacity – Hydraulic Reservoir 3.2 gal. / 12.11 L
Hydraulic Pump Fixed Displacement Gear
Machine Weight 4400 lb / 1995.81 kg
Machine Weight (CE & GOST) 107 psi / 7.49 Kg/cm2
Performance Data
Drive Speed – Platform Elevated 0.5 mph / 0.80 km/h
Drive Speed – Platform Lowered 3 mph / 4.83 km/h
Drive System 24V DC
Gradeability 25 %
Lift Time 46 sec.
Lower Time 34 sec.
Maximum Drive Height 25 ft 5 in. / 7.75 m
Platform Capacity 507 lb / 229.97 kg
Platform Capacity – Extension 265 lb / 120.20 kg
Platform Capacity – Indoor 507 lb / 229.97 kg
Platform Capacity – Outdoor 275 lb / 124.74 kg
Turning Radius – Inside 0 in. / 0 m
Turning Radius – Outside 7 ft 4 in. / 2.24 m
Dimensional Data
Ground Clearance 4 in. / 0.1 m
Machine Height 7 ft 4 in. / 2.24 m
Machine Height – Rails Folded 5 ft 10 in. / 1.79 m
Machine Length 7 ft 10 in. / 2.4 m
Machine Width 2 ft 8 in. / 0.81 m
Platform Extension Length 2 ft 10 in. / 0.86 m
Platform Height – Lowered 3 ft 8 in. / 1.11 m
Platform Railing Height 3 ft 8 in. / 1.11 m
Platform Size 16 x 5 in., Non-marking
Wheelbase 6 ft 2 in. / 1.88 m
Reach Specifications
Platform Height 25 ft 6 in. / 7.77 m
Platform Height (Indoor) 25 ft 5 in. / 7.75 m
Platform Height (Outdoor) 21 ft / 6.40 m
Working Height 31 ft 6 in. / 9.6 m

JLG 2630ES

Platform Height

7.77m / 25ft 6in

Minimum Weight

2,155.00kg / 4,7631bs

Machine Length

2.3m / 7ft 7in

Machine Height

1.94m / 6ft 5in

Turning Radius

Zero

Working Height

9.77m / 32ft tin

Safe Working Load

363.00kg / 8021bs

Machine Width

0.76m / 2ft 6in

Power Options

Electric/Battery

Gradeability

25%
